Case/Gig Bag
Deluxe Hardshell
Included Accessories
Deluxe Hardshell Case, Strap and Certificate of Authenticity.
Limited Edition Red Hot Esquire® Relic®
Limited Edition Red Hot Esquire® Relic®
Limited Edition Red Hot Esquire® Relic®
Details
Summary
Overview
The Fender Custom Shop introduces the Limited Edition Red Hot Esquire® Relic®, which blends vintage-inspired appointments with a touch of modern playability for a phenomenal playing experience. Its two-piece select ash chambered Thinline body with classic “F” hole delivers all the sweet midrange and lively response you’d expect from an ash body, presented in authentically worn-in Relic® flash-coat lacquer finishes in Aged Black, Aged White Blonde and Super-Faded Aged Candy Apple Red.
The one-piece bird’s-eye maple neck is sculpted with a 1952 “U-shaped” profile for full-hand yet super-comfortable feel, topped by a vintage compound-radius (7.25” to 9.5”) maple fingerboard with 21 medium jumbo (6150) frets and a bone nut. A single Custom Shop hand-wound reverse-angle Josefina “Red Hot” Telecaster® pickup rocks the perfect blend of bite and twang, with three-way tone switching and reverse Esquire “cocked wah” wiring.
Other premium features include a single-ply parchment pickguard, reverse Nocaster® bridge with compensated RSD (Research Special Design) brass saddles, vintage-style tuners, wing string tree, deluxe hardshell case, strap and certificate of authenticity.
Accessories
Body
Body
2-Piece Select Ash
Body Finish
Flash Coat Lacquer
Body Material
2-Piece Select Ash
Body Shape
Esquire®
Electronics
Bridge Pickup
Custom Shop Hand-Wound Josefina "Red Hot" Single-Coil Tele®
Controls
Volume, Tone
Pickup Configuration
S
Switching
3-Position Blade: Position 1. Bridge (Tone control off), Position 2. Bridge (Tone control on), Position 3. Bridge (Tone control off, preset treble roll-off)
General
Color
Aged Black
Orientation
Right-Hand
Product Name
Limited Edition Red Hot Esquire® Relic®, 1-Piece Birdseye Maple Neck Fingerboard, Aged Black
Series
Limited Edition
Hardware
Bridge
Reverse Nocaster® Bridge with Brass RSD Saddles
Control Knobs
Knurled Chrome
Hardware Finish
Nickel/Chrome
Neck Plate
4-Bolt "Limited Edition" Engraved
Pickguard
3-Ply Parchment
String Trees
American Vintage '56-'58
Strings
Nickel Plated Steel (.010-.046 Gauges)
Switch Tip
Barrel Style, Black
Tuning Machines
Vintage-Style with Fender® Logo
Measurements
Fret Size
Medium Jumbo (6150)
Scale Length
25.5" (648 mm)
Neck
Fingerboard Material
1-Piece Birdseye Maple Neck
Fingerboard Radius
7.25" to 9.5" Vintage Compound Radius (184 mm to 241 mm)
Headstock
Telecaster®
Neck Finish
Flash Coat Lacquer
Neck Material
1-Piece Birdseye Maple
Neck Shape
1952 "U"
Number of Frets
21
Nut Material
Bone
Nut Width
1.625" (41.3 mm)
Position Inlays
Black Micarta Dot - 0.25"
String Nut
Bone
Truss Rod
Vintage-Style Heel Adjust
Accessories
Case/Gig Bag
Deluxe Hardshell
Included Accessories
Deluxe Hardshell Case, Strap and Certificate of Authenticity.
Body
Body
2-Piece Select Ash
Body Finish
Flash Coat Lacquer
Body Material
2-Piece Select Ash
Body Shape
Esquire®
Electronics
Bridge Pickup
Custom Shop Hand-Wound Josefina "Red Hot" Single-Coil Tele®
Controls
Volume, Tone
Pickup Configuration
S
Switching
3-Position Blade: Position 1. Bridge (Tone control off), Position 2. Bridge (Tone control on), Position 3. Bridge (Tone control off, preset treble roll-off)
General
Color
Aged White Blonde
Orientation
Right-Hand
Product Name
Limited Edition Red Hot Esquire® Relic®, 1-Piece Birdseye Maple Neck Fingerboard, Aged White Blonde
Series
Limited Edition
Hardware
Bridge
Reverse Nocaster® Bridge with Brass RSD Saddles
Control Knobs
Knurled Chrome
Hardware Finish
Nickel/Chrome
Neck Plate
4-Bolt "Limited Edition" Engraved
Pickguard
3-Ply Parchment
String Trees
American Vintage '56-'58
Strings
Nickel Plated Steel (.010-.046 Gauges)
Switch Tip
Barrel Style, Black
Tuning Machines
Vintage-Style with Fender® Logo
Measurements
Fret Size
Medium Jumbo (6150)
Scale Length
25.5" (648 mm)
Neck
Fingerboard Material
1-Piece Birdseye Maple Neck
Fingerboard Radius
7.25" to 9.5" Vintage Compound Radius (184 mm to 241 mm)
Headstock
Telecaster®
Neck Finish
Flash Coat Lacquer
Neck Material
1-Piece Birdseye Maple
Neck Shape
1952 "U"
Number of Frets
21
Nut Material
Bone
Nut Width
1.625" (41.3 mm)
Position Inlays
Black Micarta Dot - 0.25"
String Nut
Bone
Truss Rod
Vintage-Style Heel Adjust
Accessories
Case/Gig Bag
Deluxe Hardshell
Included Accessories
Deluxe Hardshell Case, Strap and Certificate of Authenticity.
Body
Body
2-Piece Select Ash
Body Finish
Flash Coat Lacquer
Body Material
2-Piece Select Ash
Body Shape
Esquire®
Electronics
Bridge Pickup
Custom Shop Hand-Wound Josefina "Red Hot" Single-Coil Tele®
Controls
Volume, Tone
Pickup Configuration
S
Switching
3-Position Blade: Position 1. Bridge (Tone control off), Position 2. Bridge (Tone control on), Position 3. Bridge (Tone control off, preset treble roll-off)
General
Color
Super Faded Aged Candy Apple Red
Orientation
Right-Hand
Product Name
Limited Edition Red Hot Esquire® Relic®, 1-Piece Birdseye Maple Neck Fingerboard, Super Faded Aged Candy Apple Red
Series
Limited Edition
Hardware
Bridge
Reverse Nocaster® Bridge with Brass RSD Saddles
Control Knobs
Knurled Chrome
Hardware Finish
Nickel/Chrome
Neck Plate
4-Bolt "Limited Edition" Engraved
Pickguard
3-Ply Parchment
String Trees
American Vintage '56-'58
Strings
Nickel Plated Steel (.010-.046 Gauges)
Switch Tip
Barrel Style, Black
Tuning Machines
Vintage-Style with Fender® Logo
Measurements
Fret Size
Medium Jumbo (6150)
Scale Length
25.5" (648 mm)
Neck
Fingerboard Material
1-Piece Birdseye Maple Neck
Fingerboard Radius
7.25" to 9.5" Vintage Compound Radius (184 mm to 241 mm)
Headstock
Telecaster®
Neck Finish
Flash Coat Lacquer
Neck Material
1-Piece Birdseye Maple
Neck Shape
1952 "U"
Number of Frets
21
Nut Material
Bone
Nut Width
1.625" (41.3 mm)
Position Inlays
Black Micarta Dot - 0.25"
String Nut
Bone
Truss Rod
Vintage-Style Heel Adjust
